The processor main parameters:
Cortex-M3 processor highest running frequency for 100 MHz
512 kB Flash
64 kB SRAM
ISP and IAP programming
Tube feet LPC2368 compatible
Hardware configuration:
20 needle JTAG interface standards
10/100 M Ethernet interface
USB2.0 interface from equipment
USB2.0 Lord device interface
USB OTG interface (optional)
Two UART interface
Two way CAN2.0 interface
SD memory card interface
128 Chinese LCD interface x64
DA audio interface (LM386)
8 a controllable LED
AD adjustable resistance
24 C04 serial EEPROM
By external interruption buttons
The network part:
Http web server program-on the control board LED by web pages, and went to board to send data, read LCD AD value, etc.
Uip web server program-protocol stack code open.
USB part:
USB the main controller reading and writing U plate program-provide the source code.
USB mass storage program-provides RAM plate operating mode.
USB HID equipment program-this control type of equipment to make good points.
USB Bootloader program-U disk mode applications, the most updated convenient way.
CAN part:
With the operating system CAN program-LPC1768 take two road CAN not meet many other board CAN test the communication CAN, at the proven RTX operation under the performance of the system.
SD storage part:
Take the file system SD card program-FAT16 file system, the biggest support 2 gb SD card.
Other small test procedures:
NXP provide convenience to users faster LPC17xx internal and peripherals to resources of the process, we don't know how to match the register to drill here will find satisfying method, and the program contains GPIO, EXTINT, UART, PWM, ADC and DAC, Timer, SPI, IIC......
Basic function:
LPLC1768 ARM7 x1 development board
USB line x1
Serial line x1
Crossover cable x1
CD: development x1
TE40
