Features
Power
Powered from USB bus or from an external 5V power supply using an onboard 3.3V regulator AMS1117
Protection Circuit for anti-overload and anti-reverse
Onboard Chips
ATxmega A1 Series, Device Board with a xmega microcontroller can be separated from the motherboard
FT232RL, USB-UART chip, with two Indicator LED
MT48LC16M4A2, 64Mb SDRAM, controlled by the EBI interface of xmega
FM24CL04, 4Kb F-RAM, which features HIgh Speed, Nonvolatile and High Endurance
MAX3232, RS232-UART chip, communicating with the host computer via two RS232 interface
Module and Interface
Infrared Module, for remote data transmission using the IRDA controller of xmega
LCD12864 Interface, supports mounting external LCD module, controlled by parallel or SPI
SDCard Slot, Read/Write via SPI
Passive Buzzer, plays music via PWM
Analogous Circuit
Photosensitive Resistor, for AD experiment
Thermosensitive Resistor, for AD experiment
Adjustable Resistor, whose Mid-terminal connects to the AD interface of xmega, for AD experiment
Human-computer Interface
4 LED
External LCD module interface
3 Push-buttons
1 Joystick
Other Resources
Crystal Socket, for easy mounting external crystal
Indicates all the GPIO
Emulation/Program Interface
JTAG Interface (10 PIN), compatible with official standard from ATMEL
PDI Interface (6 PIN), compatible with official standard from ATMEL
--------------------------------------------------------------------------------
Development Resources
User Guide CD
CD with software, drivers and examples
Schematic Circuit Diagram
Designed by using Protel
Provides IMG format or Protel SchDoc format
Program Examples
Designed by using GCCAVR
Provides drivers from ATMEL
Related Software
AVRStudio
ICCAVR - 45 DAYS DEMO
Winavr(GCCAVR)
Datasheets of the chips
Package Contains:
EVK XA1 x 1
USB Cable (mini) x 1
USB Cable for sourcing power x 1
RS232 Cable x 1
Experiment Fittings Pack x 1
User Manual CD x 1
TE66
