SPECIFICATIONS
Basic
Functions
Range
Accuracy
VA20
VA20B
VA20C
VA21
DC Voltage
200mV/2V/20V/200V/600V
/400mV/4V/40V/
400V/1000V
±(0.7%+2)
±(0.7%+2)
±(0.7%+2)
±(0.7%+3)
AC Voltage
200mV/2V/20V/200V/600V
4V/40V/400V/750V
±(1%+3)
±(1%+3)
±(1%+3)
±(1.2%+3)
DC Current
200μA/2mA/20mA/200mA/2A
/10A/4000μA/400mA/10A
±(2%+10)
±(2%+10)
±(2%+10)
±(2%+8)
AC Current
200μA/2mA/20mA/200mA/2A
/10A/ 4000μA/400mA/10A
±(3%+10)
±(3%+10)
±(3%+10)
±(3%+8)
Resistance
200Ω/2KΩ/20KΩ/200KΩ/2MΩ
/20MΩ/400Ω/4KΩ/40KΩ/
400KΩ/4MΩ/40MΩ
±(1%+5)
±(1%+5)
±(1%+5)
±(2%+5)
Capacitance
20nF/200nF/2μF/20μF/200μF
/1000μF/4nF/40nF/400nF
/4μF/40μF/200μF
±(4%+10)
±(5%+5)
Temperature
-20°C~1000°C
-40°C~750°C
±(1%+3°C)
±(1%+4°C)
±(1%+4°C)
0°F~1800°F
±(1%+5°F)
±(1%+7°F)
Frequency
10HZ~200KHZ
±(0.1%+1)
Special Functions
VA20
VA20B
VA20C VA21
Continuity Check
√
√
√
√
Diode Test
√
√
√
√
Transistor hFE Test
√
√
AutoRange
√
√
√
√
Misplug Alarm
√
No Contact AC Voltage Detector
√
√
√
√
Back Light
√
√
√
√
MAX Value Measurement
√
√
√
Relative Measurement
√
MAX/MIN Value Measurement
√
Data Hold
√
√
√
√
Auto Power Off
√
√
√
√
Low Power Indication
√
√
√
√
Max. Display
1999
1999
1999
3999
We only accept the payment through Paypal. Payment should be made within 7 days after the order placed.
The item(s) will be shipped by Airmail with Insurance from Hong Kong. The item(s) will be sent within 2 working days after payment received.
Approximate Delivery Time
Delivery Time Countries
7 ~ 12 days United States, United Kingdom, Canada, Australia and New Zealand
7 ~ 15 days Germany, France, Spain, Italy, Netherlands, Belgium, Austria and Switzerland
7 ~ 15 days Rest of the world
*Delivery time might be longer if the item(s) be inspected by customs*
Return Policy
If you receive defective item(s), please kindly notify us within 7 days. We will guide you the returning instruction for replacement. The item(s) must be returned with fully packed material without being used.
The returning shipping cost will be your expenses by Registered Airmail. Once we receive your returning unit, we will investigate the unit within 7 days. We will then send you a brand new replacement unit at our shipping cost.
Custom Taxes
A small parcel would be less likely imposed taxes or duties by customs. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility.
Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying.
Model number:94
