Key Features:
● Display: 6000 counts
● USB port connect to PC
● Relative measument
● Auto power off
● Data hold
● Back light
● Auto/manual range
● Low power indication
● Diode/Continuity test
This instrument complies with IEC 61010-1：2001, CAT II 1000V and CAT III 600V overvoltage standards. See Specifications
SPECIFICATIONS
Basic Functions
Range
Accuracy
DC Voltage
600mV
6V/60V/600V
1000V
±0.5%
±0.8%
±1.0%
AC Voltage
600mV/6V/60V/600V
1000V
±1.0%
±1.5%
DC Current
600μA/6000μA/60mA/600mA/6A/10A
±1.5%
AC Current
600μA/6000μA/60mA/600mA
6A/10A
±1.8%
±3.0%
Resistance
600Ω/6KΩ/60KΩ/600KΩ/6MΩ
60MΩ
±0.5%
±1.5%
Capacitance
60nF
600nF/6μF/60μF/300μF
±3.0%
±5.0%
Logic Frequency
1Hz~1MHz
±(0.1%+3)
Line Frequency
6Hz~10KHz
±(0.05%+8)
Duty Cycle
1%~99%
Temperature -55℃~0℃
1℃~1000℃
±5.0%
±2.0%
General Characteristics
Power : 6F22(9V) x1 ( battery not included )
Product Size: 190(L)x90(W)x40(H) mm
Weight: 500g. Approx.
Standard Individual Packing: Gift Box
Standard Accessories:
●User's manual
One piece
● Test leads
One piece
●"K" type Thermocouple
One piece
● Capacitor test lead
One piece
●USB line
One piece
● PC-Link software CD
One piece
We only accept the payment through Paypal. Payment should be made within 7 days after the order placed.
The item(s) will be shipped by Airmail with Insurance from Hong Kong. The item(s) will be sent within 2 working days after payment received.
Approximate Delivery Time
Delivery Time Countries
7 ~ 12 days United States, United Kingdom, Canada, Australia and New Zealand
7 ~ 15 days Germany, France, Spain, Italy, Netherlands, Belgium, Austria and Switzerland
7 ~ 15 days Rest of the world
*Delivery time might be longer if the item(s) be inspected by customs*
Return Policy
If you receive defective item(s), please kindly notify us within 7 days. We will guide you the returning instruction for replacement. The item(s) must be returned with fully packed material without being used.
The returning shipping cost will be your expenses by Registered Airmail. Once we receive your returning unit, we will investigate the unit within 7 days. We will then send you a brand new replacement unit at our shipping cost.
Custom Taxes
A small parcel would be less likely imposed taxes or duties by customs. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility.
Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying.
Model number:91
